| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Country of Origin | India |
| Type | Automobiles Turntable |
| Thickness | 1-5mm |
| Click to view more | |
Product Details
No. of Pcs/Box: 2 Pcs
Gross Weight: 20.000kg
Description:
- Sarv manufacturers a range of high precision Wheel Alignment Turn plates for high accuracy in Wheel Alignment Measurements.
- Turn plates are free floating with 360 degree movement in all directions , due to steel balls underneath in plastic cage which provide a low friction movement , and aid measure a variety of Alignment angles with accuracy.
- All Sarv Turn plates are robust with industrial grade designs and perfect for long term use.
- Comes with dual pin locking system to provide stability of slip plate for keeping the plates zeroed and in position while the vehicle drives up on them or even while turn plates are not in use.
- These are equipped with built in handle for easy carriage and auto centering design
- This particular alignment Turntable is made from heavy duty steel , and black powder coated for anti rust finish and extended life span.
Additional Images
-
Wheel Alignment Turn Plate for Passenger Car
Size : L-320mm, W- 400mm, H-50mm
Capacity : 1000kg
Dia : Top Plate – 275mm
Weight : 9.250 kg
Material : Made from heavy duty steel sheet. Black Powder Coated to prevent rusting. 24 Steel balls(Dia 15mm) used in plastic cage.
-
Wheel Alignment Turn Plate For Paasenger Car
Code : 1100117
Size : L-380mm, W-350mm, H-45mm
Capacity : 1000kg each having scale of ± 0° – 60°
Dia : Top Plate – 310mm
Weight : 9.750kg
Material : Made from heavy duty steel sheet. Steel balls(Ø15mm) used in plastic cage.
-
Wheel Alignment Turn Plate for Passenger Car
Code : 1100817
Size : L-370mm, W-370mm, H-50mm
Capacity : 1500kg each having scale of ± 0° – 60°
Dia : Top Plate – 350mm
Weight : 12.440kg
Material : Made from heavy duty steel sheet. Electroplated to prevent rusting. 36 Steel balls(Dia12mm) used in plastic cage.
-
Wheel Alignment Turn Plate 1100817 with Run Up Ramp for Passenger Car
Code : 1101017
Size : L-370mm, W- 670mm, H-53mm
Capacity : 1500kg each having scale of ± 0° – 60°
Dia : Top Plate – 350mm
Weight : 25.00kg
Material : Special Steel. Electro less Nickel Plating. 36 Steel balls(Ø12mm) used in plastic cage.
-
Light Weight Wheel Alignment Aluminium Turn Plate with Rubber stopper for Passenger Car
Code : 1101317
Size : L-395mm, W-395mm, H-50mm
Capacity : 1500kg each having scale of ± 0° – 60°
Dia : Top Plate – 350mm
Weight : 6.700kg
Material : Made from special grade of Aluminum. 88 Plastic balls(Dia10mm) used in plastic cage.
-
Rubber Stopper for Mechanical Turn Table 1101317Size : 322mmx55mmx16mm
Code : 1101317RS
Size : L-322mm, W-55mm, H-16mm
Weight : 153gms per pc.
